The Front Porch Security Bundle

View your porch in 1080p HD
Lock/unlock the front door remotely
View motion events and lock history
Works with Alexa and Google Assistant

Wyze Video Doorbell
Power: 16V-24V AC, ≥10VA (May use existing doorbell-chime circuit, or standalone transformer and wires.)
Weight: 1.7oz / 49gSize: 1.5'' x 3.25'' x 0.625''
Image Sensor: 2K (2048 x 1536)
Camera: F2.0 aperture, 2.7mm focal length, 1/2.8" CMOS
Image Quality: 1080p and 480p w/ 8x Digital Zoom
Frames per Second: 20 Daytime, 15 Nighttime
Audio: Built in Speaker & Microphone (with 2-way Audio & Noise/Echo Cancellation)
White LED (Fill Light): 6 x 5000K (daylight color temperature)
IR Night Light: 4 x 940nm Infrared LED
Connectivity: Direct to WiFi 802.11 b/g/n, 2.4GHz (5GHz WiFi not supported)
Sub1G: 906.8MHz, used for local connection between doorbell and chime.
IP65 Weather-resistant
Storage Temperature: -40 to 176°F (-40 to 80°C)
Operating Temperature: -4 to 122°F (-20 to 50°C)
Field of View: 120° Vertical x 88° Horizontal
Operating Systems: iOS 9.0 and Android 5.0 or later
Data Security: End-to-end encryption, HTTPS secure transfer protocol, AES 128-bit encryption
Wyze Chime
Chime Power: Standard US Power Outlet: 100V-240V, 0.1A, 50/60Hz
Weight: 2.0 oz / 56g
Size: 2'' x 2'' x 1.4''
Chimes: 5 modern, 4 classic doorbell, 3 animal sounds, 6 automation sounds, 1 intruder alarm
Lock

Color
Silver
Dimensions
4.9" Length x 2.5" Width x 1.3" Depth (2" including knob)
Weight
0.67 lb
Power Source
4x AA Batteries (included)
Battery Life
5-6 months (depending on usage)
Communication Method
Bluetooth, Zigbee
Range
To Keypad: 9', To Gateway: 50', BLE to phone: 16'
Compatibility
Android 5.0+, iOS 9.0+
Weather Resistance
Indoor use only
Operating Temperature
14°F - 131°F / -10°C - 55°C
Storage Temperature
-22°F - 158°F / -30°C - 70°C

Keypad (sold separately)

Color
Silver
Dimensions
3.7" Length x 1.3" Width x 1.0" Depth
Weight
0.1 lb
Power Source
2x AA Batteries (included)
Battery Life
4-6 months (depending on temperature)
Communication Method
Bluetooth
Range
To Lock: 9'
Compatibility
Android 5.0+, iOS 9.0+
Weather Resistance
IPX5
Operating Temperature
-4°F - 140°F / -20°C - 60°C
Storage Temperature
-22°F - 158°F / -30°C - 70°C

Gateway

Color
White
Dimensions
2.1" Length x 2.1" Width x 1.2" Depth (1.9" including pins)
Weight
0.12 lb
Power Source
110-240V, ~60Hz
Battery Life
NA
Communication Method
Bluetooth, Zigbee, Wifi
Range
To Lock: 50', To Router: 50
Compatibility
Android 5.0+, iOS 9.0+
Weather Resistance
Indoor use only
Operating Temperature
14°F - 131°F / -10°C - 55°C
Storage Temperature
-22°F - 158°F / -30°C - 70°C

Wyze Lock x1
Wyze Lock Gateway x1
AA Batteries x4
Adhesive Strip x1
Mounting Plate x1
Adapter x3
Quick Start Guide x1


Wyze Video Doorbell + Chime
Wyze Video Doorbell x1
Wyze Chime x1
Wall Plate x1
Wedge (Horizontal, 30°) x1
Wire Caps x4
Bracket Screws x2
Screws & Expansion Tubes x2
Extension Wires x2
Fuse x1
Quick Start Guide x1
